East, west, north, south: How to fix your local cluster routes
Introduction
Recently I needed to test a Keycloak upgrade. This required me to deploy both the new Keycloak version and a sample OIDC application on my local Kubernetes setup. And it pointed me to a thing I kept postponing:
Improve my local development DNS, routing and TLS setup
The challenge
Until recently, I used urls like keycloak.127.0.0.1.nip.io:8443
. This points to 127.0.0.1
port 8443
which forwards to a local k3d cluster. At the same time it provides a unique hostname that can be used for configuring ingress.
Nice. But not without flaws.
For starters, this works for routing traffic to the K3D cluster, we could call this ‘north-south’. But not for routing traffic within the cluster (east-west). This becomes apparent when trying to setup an OIDC sample application1, such as the one shipped with DEX. The domain pointing to Keycloak is used in two places: By the browser of the user logging in, so in this case from the host OS, and directly from the backend, so within the cluster.
This puts us in a catch-22: nip.io
, or an entry in /etc/hosts
only works for north-south. svc.cluster.local
only works for east-west.
Another problem is that the default certificates issued by Traefik, are not trusted by other systems or browsers. So we frequently need to bypass security warnings, which by itself is indicative of a problem and encourages bad habits. Furthermore, even if we manage to configure our setup to use the ingress service from within the cluster, it depends on the backend application if it allows bypassing TLS host checking.
Problem routing both north-south and east-west traffic
To improve this, we need to address some things. In this article:
☞ Don’t fancy reading? Head straight to the github repo containing taskfile automation
The plan
So, let’s identify and configure the components needed to create a smooth local Kubernetes setup, providing trusted TLS and predictable endpoints.
This will result in applications being accessible via the following pattern:
k3d cluster | Hostnames | HTTP port | HTTPS port |
---|---|---|---|
cl0 | *.cl0.k3d.local | 10080 | 10443 |
cl1 | *.cl1.k3d.local | 11080 | 11443 |
cl2 | *.cl2.k3d.local | 12080 | 12443 |
etc, etc… |

East, west, north, south. The components used to fix the routes. Source: Wikimedia & Open Source projects
Improvement 1: TLS certificates and trust
Create CA certificate and key
The ingress configurations in the cluster need to serve a certificate that is trusted by browsers and systems. One way could be registering a public (sub)domain for internal use, and use Let’s Encrypt certificates, using DNS-01 challenge for verification.
Another way is to create a self-signed Certificate Authority (CA), use that to issue TLS certificates, and ensure the CA is trusted by the relevant systems. I chose this approach since it’s mostly a setup-once affair, and doesn’t require me to deal with API tokens of my DNS provider.
One important thing to be aware of, is that adding a CA to a trust bundle, has any certificate signed by it, to be trusted. So, if the CA signs a certificate for e.g. myaccount.google.com
, your browser will trust it. This can be mitigated by adding NameConstraints. This reduces the risk of adding self-signed CAs to your trust bundles.
Create a ca.ini
file:
[ req ]
default_bits = 4096
distinguished_name = req_distinguished_name
req_extensions = v3_req
prompt = no
[ req_distinguished_name ]
CN = Development Setup .local CA
O = LocalDev
C = NL
[ v3_req ]
basicConstraints = critical, CA:TRUE
keyUsage = critical, keyCertSign, cRLSign
nameConstraints = critical, permitted;DNS:.local
Create key, certificate signing request (csr) and signed certificate:
openssl ecparam -name prime256v1 -genkey -noout -out ca.key
openssl req -new -key ca.key -out ca.csr -config ca.ini
openssl x509 -req -in ca.csr -signkey ca.key -out ca.crt -days 3650 -extfile ca.ini -extensions v3_req
# Show the certificate
openssl x509 -noout -text -in ca.crt
Note the name constraints section:
X509v3 extensions:
X509v3 Name Constraints: critical
Permitted:
DNS:.local
Let’s test if name constraints works by issuing a certificate that does not match the name constraint:
# Create a certificate for example.com
openssl req -x509 -newkey rsa:4096 -sha256 -days 3650 \
-CA ca.crt -CAkey ca.key \
-nodes -keyout example.com.key -out example.com.crt -subj "/CN=example.com" \
-addext "subjectAltName=DNS:example.com,DNS:*.example.com,IP:10.0.0.1"
# Ok, so we can create a certificate outside the name constraints
# Let's verify it
openssl verify -verbose -CAfile ca.crt example.com.crt
This results in:
CN=example.com
error 47 at 0 depth lookup: permitted subtree violation
error example.com.crt: verification failed
Good! Now add the CA to Keychain:
sudo security add-trusted-cert -d -r trustRoot -k /Library/Keychains/System.keychain ca.crt
Setup Kubernetes cluster issuer and trust bundle
We can now install cert-manager to issue TLS certificates and trust-manager to distribute trust bundles:
helm repo add jetstack https://charts.jetstack.io --force-update
# cert-manager
# Note the NameConstraints feature gates!
helm upgrade --install \
cert-manager jetstack/cert-manager \
--namespace cert-manager \
--create-namespace \
--set crds.enabled=true \
--set webhook.featureGates="NameConstraints=true" \
--set featureGates="NameConstraints=true"
# trust-manager
helm upgrade --install \
trust-manager jetstack/trust-manager \
--namespace cert-manager
Add the CA certificate and create a ClusterIssuer
:
kubectl -n cert-manager create secret tls root-ca --cert=ca.crt --key=ca.key
cat <<EOF | kubectl apply -f -
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
name: root-ca
spec:
ca:
secretName: root-ca
EOF
Create a trust Bundle
:
cat <<EOF | kubectl apply -f -
apiVersion: trust.cert-manager.io/v1alpha1
kind: Bundle
metadata:
name: default-ca-bundle
spec:
sources:
- useDefaultCAs: true
- secret:
name: "root-ca"
key: "tls.crt"
target:
configMap:
key: "bundle.pem"
namespaceSelector:
matchLabels:
trust: enabled
Now the bits of configuration we need to remember when setting up applications:
- The cluster issuer name is
root-ca
, so Ingress objects need the annotationcert-manager.io/cluster-issuer: root-ca
- The CA bundle, including our issuer CA, can be found in a ConfigMap
default-ca-bundle
under keypundle.pem
, if the namespace is labeledtrust: enabled
.
Note: Since I consider dev clusters ephemeral and short-lived, topics like safely rotating issuer certificates don’t need attention. When setting up trust manager in production environments, be sure to consider what namespace to install in and prepare for issuer certificate rotation.
Improvement 2: Fixing north-south routing
As mentioned in the introduction, DNS resolvers like nip.io
are helpful for routing from host to development cluster, but will not work within the cluster: It will resolve to 127.0.0.1
and the target service won’t be there.
One way to handle this is to install dnsmasq, and configure resolving on the host in such a way that .local
will use 127.0.0.1
to resolve DNS. Which will then respond with 127.0.0.1
. Using the port matching the K3D cluster will then ensure the correct cluster receives the traffic.
brew install dnsmasq
# Ensure service can bind to port 53 and starts at reboot
sudo brew services start dnsmasq
Configure dnsmasq, use brew --prefix
to determine where the config is located. On a silicon Mac that will be /opt/homebrew
.
Ensure the following line in /opt/homebrew/etc/dnsmasq.conf
is uncommented:
conf-dir=/opt/homebrew/etc/dnsmasq.d/,*.conf
Then we can configure dnsmasq to resolve .local
to 127.0.0.1
:
echo "address=/local/127.0.0.1" > $(brew --prefix)/etc/dnsmasq.d/local.conf
Finally, we tell macOS to use dnsmasq at 127.0.0.1
to resolve DNS queries for .local
:
sudo sh -c "echo 'nameserver 127.0.0.1' > /etc/resolver/local"
Be aware that tools like dig
and nslookup
behave a bit different from the usual program on macOS so they are not the best way to test2. If we have set up a K3D cluster, mapping host ports to the http and https ports using -p
, we could try to reach an application:
# Assuming we have set up keycloak and port 10443 is forwarded to k3d https port
# Using -k since curl does not use the system trust bundle, so is not aware of our CA
curl -k https://keycloak.cl0.k3d.local:10443/ -I
HTTP/2 302
location: https://keycloak.cl0.k3d.local:10443/admin/
Application is there. Good. Let’s move on.
Improvement 3: Fixing east-west routing
Our dnsmasq setup works from host, via ingress to a service. But when needing to access another service within the cluster, using the same domain, it won’t.
Of course, we can access services the usual way via service-name.namespace.svc.cluster.local
. But this means within the cluster we need to use a different domain than from the outside. Confusing at best, and in some cases not possible. One example being Keycloak client applications, as outlined in the introduction, where only one configuration item for the Keycloak domain exists.
If, from within our cluster, we try to resolve keycloak.cl0.k3d.local
from a pod, the following happens:
- CoreDNS knows nothing about this, it’s not a pod, it’s not a service
- CoreDNS forwards DNS resolving to host
- The host (our Macbook) will recognize
.local
and tell DNS to query for the domain at127.0.0.1:53
- There is no DNS server running in the pod so DNS resolving will fail
To fix this, we make two adjustments.
First, we copy the existing traefik
service to traefik-internal
, changing the type from LoadBalancer
into ClusterIP
and adjusting the ports to align with the ports mapped to the host. The resulting service looks like this:
apiVersion: v1
kind: Service
metadata:
name: traefik-internal
namespace: kube-system
spec:
ports:
- name: webext
port: 10080
protocol: TCP
targetPort: web
- name: websecureext
port: 10443
protocol: TCP
targetPort: websecure
selector:
app.kubernetes.io/instance: traefik-kube-system
app.kubernetes.io/name: traefik
type: ClusterIP
Next, we need to ensure that connecting to e.g. keycloak.cl0.k3d.local
from within our cluster, will end up at the traefik-internal
service.
For this we can add a custom dns entry to CoreDNS. We can do so by adding a configmap:
apiVersion: v1
kind: ConfigMap
metadata:
name: coredns-custom
namespace: kube-system
data:
k3d.local.server: |
k3d.local:53 {
errors
cache 30
rewrite name regex (.*)\.cl0\.k3d\.local traefik-internal.kube-system.svc.cluster.local
# We need to rewrite everything coming into this configuration block to avoid infinite loops
rewrite name regex (.*)\.k3d\.local host.k3d.internal
forward . 127.0.0.1:53
}
Note: As the comment says, we need to ensure we rewrite everything, since we feed the rewritten domain back to CoreDNS. This is why using k3d.local
as domain to put clusters under, works fine, whereas k3d.internal
does not. In case of the latter, we would rewrite to a new FQDN that re-enters the custom config, resulting in an infinite loop and CoreDNS crash.
With the 3 improvements in place, we now have a setup that works:
Consistent DNS and trusted certificates
Combining and automating
Although we now have a configuration that works, it is not particularly easy to set up. So, what do we do? We automate.
Taskfile is single-binary Make
alternative that provides all the templating and configurability needed, to easily spin up K3D clusters configured as described in this article.
Check out the dev-cluster-config repository. Then:
# review .default.env
cat .default.env
# If needing to adjust config
cp .default.env .env
vim .env
# Once: Setup CA certificate
task cert
# Once: Setup dnsmasq
task dnsmasq_brew
# Setup & configure clusters
task k3d-cluster-setup-0
task k3d-cluster-setup-1
# Optionally: Add example applications (nginx/curl)
task k3d-cluster-examples-0
task k3d-cluster-examples-1
# Use k3d to remove a cluster
k3d cluster delete cl0
k3d cluster delete cl1
Next steps and wrapping it up
Optionally, we could also set up a load balancer like haproxy on the macOS host that listens on the default http and https ports 80 and 443. It would serve the trusted certificate and, based on host, forward to the proper k3d cluster. This would remove the need to use custom ports.
If on the other hand, one does not want to set up dnsmasq, one could address clusters like myapp.cl1.k3d.127.0.0.1.nip.io
, and update the CoreDNS configuration accordingly, to intercept DNS lookups to *.k3d.127.0.0.1.nip.io
and return the host host.k3d.internal
IP address.
The setup described in this article, consists of several discrete parts. It is not a one-stop integrated solution. However, as illustrated above, it can be easily extended and adjusted, so that can be considered an advantage. If wanting to run Kind, Minikube, Rancher Desktop or Colima, a similar approach will work.
Now, local development setups, like OS and editor choices, is typically something engineers are very opinionated about. And that’s fine!3 So, if you are wondering “why are you doing all this and not doing this other thing instead?". By all means, reach out on LinkedIn or BlueSky. I’m curious!
Regardless, I hope the above provides some guidance on getting the most out of your local development clusters.
-
Yes, we are mixing Keycloak and DEX. The beauty of standards such as OIDC. ↩︎
-
It’s… complicated. This article about configuring DNS and VPN gives some insights. ↩︎
-
Although there is often a balance to strike between ‘own improvements’ and ‘team standards’. ↩︎
